SW Smart Film Switchable Electric PDLC Smart Glass Window Tint for Home, Office Meeting Room, 6”X6”, Sample

PDLC is a film-based product that combines rod-shaped liquid crystals with prepolymers and adheres to transparent conductive substrates, so it has both liquid and crystal characteristics, as well as significant optical and electrical properties. In the absence of an electric field, its molecules are arranged disorderly, making it opaque, and under the action of an electric field, the molecules are arranged orderly along the direction of the electric field, making it transparent. By controlling the electric field, it can be transformed between transparent and opaque states. So it is opaque when power off, it is transparent when power on Specifications: Material: PDLC(Polymer Dispersed Liquid Crystal), Imported Liquid Crystal and ITO Film Color: Translucent White Size: 6”X6” (And any size can be customized, want other size, please contact us) Features: Self-adhesive, anti uv, heat control, anti aging, anti fade, anti shatter, energy saving, environmentally friendly Haze: ON: <7%, OFF: >90% View Angle: ON: around 150° SHGC: ON: 0.78, OFF: 0.06 IR Blocking: ON: >30%, OFF: 90% UV Blocking: ON: 90%, OFF: 99% Response Time: ON to OFF: <20ms Power Consumption(On): <5W/㎡ Thickness(N/A): 0.54mm Service Life(Indoor): More than 10 years Operating Temperature(ON to OFF): -20℃ to 70℃ Transmission/Parallel Light: ON: About 84%(±1) , OFF: <3 Wide Application: Office doors and windows, meeting room, reception room, private room, wash room, bathroom Medical wards, operating rooms of hospitals, monitoring rooms, police station, court ect. jewelry shop, museums, insurance counters, automatic equipment ect. Large-scale projection screens Any place which needs 24 hours privacy Package Includes: 1 x PDLC smart film 1 x power supply

• PDLC is a membrane-based product that combines rod-shaped liquid crystals with prepolymers and adheres to transparent conductive substrates, so it has both liquid and crystal characteristics, as well as significant optical and electrical properties. In the absence of an electric field, its molecules are arranged disorderly, making it opaque, and under the action of an electric field, the molecules are arranged orderly along the direction of the electric field, making it transparent
• PRIVACY PROTECTION - The biggest feature of PDLC smart film is privacy protection function. By controlling the electric field, it can be transformed between transparent and opaque states. So it is opaque when power off, it is transparent when power on
• PROJECTION FUNCTION - PDLC smart film not only can protect 24 hours privacy, but also it is an excellent projection screen, the projection effect is very outstanding. Family cinema, office projection, one smart film gets all done
• ENERGY SAVING and ENVIRONMENTLLY FRIENDLLY - In the power-on state, only 5 W per square meter of electricity is consumed per hour. PDLC smart film can reject 90% infrared and 99% ultraviolet. Rejecting infrared ray can reduce heat radiation and transmission, while can protect indoor furnishings from fading and aging, and protect people from diseases caused by direct ultraviolet radiation
• AFTERSALES SERVICE - Any size can be ustomized, just tell us the exact size, we are always here for you
